1. Company Introduction
About Us
We specialize in intelligent wire mesh machinery and automated supporting solutions, covering a full range of wire mesh production equipment. With over 40 years of manufacturing experience, we offer stable, efficient and customizable machines. We also provide professional technical support, complete spare parts supply and reliable after-sales services.
2.160B Wire Mesh Weaving Machine Core Advantages & Selling Points
The AG160B is a fully automatic wire mesh weaving machine with a 1600 mm effective working width. It is suitable for plain, twill and Dutch weaving of stainless steel wire, copper wire, aluminum wire, nickel wire, tungsten wire, titanium wire and other metal wires. Designed for large-width, high-mesh, high-density and fine-wire metal mesh continuous production, it is suitable for large-size precision filter mesh, industrial screening mesh, protective mesh and special metal mesh materials for industrial supporting.
1.Exclusive EtherCAT Bus Control (Unique in the Market)
Adopts advanced EtherCAT multi-axis bus system instead of traditional pulse control. It realizes high-precision synchronous operation of multiple axes under large-width weaving condition, effectively avoids belt skipping, stalling and jamming problems caused by increased weaving width, ensures ultra-stable high-speed operation of large-format mesh weaving, and greatly reduces equipment failure rate and downtime loss.
2. Full CNC & Mechatronic Integrated Design
Sword belt feeding, warp tension control, weaving and rolling are fully digitally controlled. It solves the problem of uneven tension and irregular mesh holes easily occurring in large-width mesh production, maintains constant overall tension of the mesh surface, guarantees flat large-size mesh surface, uniform hole size and consistent weaving quality. Equipped with enhanced heavy-duty beating mechanism for tighter, flatter and neater large-width mesh structure.
3. Highly Automatic & Intelligent Operation
Full automatic weaving, intelligent constant tension adjustment and synchronous rolling system are matched for large-width production. Optimized mechanical structure design reduces wearing parts consumption, lowers daily maintenance cost and extends equipment overall service life. Supports remote diagnosis and remote real-time technical support, quickly locates and solves operating faults without on-site service, and ensures continuous and efficient production of large-volume mesh products.
4. Strong Customization Capability
We provide personalized machine parameter customization and structural optimization according to customer’s wire diameter, mesh count, mesh width and different mass production requirements. Targeted flexible production solutions are available for various large-width, special-spec metal mesh products to meet diversified industrial production demands.
5.Complete Trial & Processing Service
Support on-site machine testing, free trial weaving of various large-width metal mesh and OEM processing service. Customers can verify large-size mesh weaving effect, precision and stability on site before formal mass production, realizing zero-risk order docking and production launch.
6.Professional Training & After-sales Service
We provide full on-site equipment operation, parameter debugging and daily maintenance training for inexperienced production teams. For orders of 10 units and above, we offer free on-site installation, commissioning and systematic technical training within one week (no labor fee, only necessary translation and actual expenses).
Key Highlights in One Sentence
The exclusive large-width EtherCAT bus-controlled mesh loom on the market, 1600mm ultra-wide working width, fully automatic intelligent operation, low failure rate, stable high-precision large-format weaving quality, customizable specifications, with complete trial weaving service and professional remote & on-site after-sales support.
3.Typical Applications & On-site Cases
The machine is widely used for mass production of large-width copper mesh, stainless steel mesh, titanium mesh, nickel mesh and various special metal wire mesh products. The following photos show the actual application status, production operation environment, standard operation method and finished large-width mesh product effect of similar-series machines in customer factories, providing intuitive production reference for customers.
|
Copper mesh weaving site: Shows continuous copper mesh weaving, suitable for conductive, shielding and filtration applications.
|
Copper mesh weaving detail: Shows stable mesh forming and the copper wire weaving/output condition.
|
|
Stainless steel mesh production site: Suitable for continuous production of precision filter mesh and industrial screening mesh.
|
India customer factory training case: Supports customer factory training, pre-shipment inspection, trial running and process communication.
|
|
These pictures show the customer's large workshop. Multiple mesh looms are running steadily for mass industrial production.
|
These are on-site photos of our wire mesh looms put into formal production at the customer’s factory.
|
4. Warranty & After-sales Service
|
Item
|
/Specification / Description
|
|
Delivery Time
|
25Standard delivery time is 25 working days. The exact delivery schedule is subject to order configuration, production schedule and contract terms.
|
|
/Factory Acceptance / Inspection
|
Customers are welcome to visit the factory for pre-shipment inspection and trial running, confirming machine status, target process and finished mesh surface.
|
|
Customer Training
|
Free factory training is available, covering basic operation, common specification changeover, routine maintenance, troubleshooting and process parameter communication.
|
|
Overseas Installation & Commissioning
|
According to order quantity and project requirements, engineer on-site installation and commissioning service can be provided. Service scope, duration and cost arrangement are subject to the contract.
|
|
Online Support
|
If customers cannot visit the site, video guidance, online installation/commissioning support and operation training can be provided. Electrical parts can be remotely assisted.
|
|
After-sales Service Commitment
|
Long-term technical support and spare parts service are available. Warranty period, response method, spare parts list and service standards are subject to the final contract.
|
5. Business Contact
|
/ Website
www.machine-gabion.com
|
/ Email
admin@machine-gabion.com
|
/ WhatsApp / Tel / WhatsApp
+86 13623378003
|
|
AG130D Please provide target mesh samples, wire diameter, mesh count, material and capacity requirements so that we can recommend suitable AG130B configuration and process solutions.
|
