SLW‑58A High‑Efficiency Automatic Hexagonal Gabion Mesh Manufacturing Line
| Place of Origin | CHIAN |
| Brand Name | APBWR |
| Certification | ISO9001 |
| Model Number | SLW-58A |
automatic gabion mesh manufacturing line
,high-efficiency hexagonal gabion production line
,gabion mesh machine with warranty
1.Production Capacity Advantages of Gabion Production Line
This gabion production line built around SLW‑58A realizes full‑automated continuous production. The gabion production line can reach output above 1000 ㎡ every hour. One gabion production line can switch production targets between gabion box sheets and slope‑protection mesh rolls freely. It greatly cuts labor demand and lowers comprehensive operating cost for factories running this gabion production line.
2.SLW‑58A Main Machine Technical Features
The core unit of this gabion production line‑SLW‑58A is driven by 5 sets of 15kW HCFA servo motors. The gabion production line supports triple‑twist, five‑twist, long twist and short twist weaving modes. Maximum weaving width reaches 5.4‑5.7m and can be customized further; applicable max galvanized wire diameter is 4mm. The host weight of this gabion production line hits 19.5 tons for stable heavy‑duty work.
3.Modular Auxiliary Configuration for Gabion Production Line
Each auxiliary device of this gabion production line is modular‑designed. Users can configure stations according to their actual workshop layout and product portfolio of the gabion production line. Available modules contain tension adjustment, spiral wire processing, mesh cutting, edge finishing, mesh rolling, hydraulic baling and straight‑wire cutting, flexible for small‑batch and mass‑batch orders on the gabion production line.
4.Product Quality Control of Gabion Production Line
Constant‑closed‑loop tension control is adopted in this gabion production line, keeping wire tension within 350‑500N during weaving. Every mesh aperture and twist length produced by the gabion production line maintains high consistency, effectively avoiding dimensional deviation caused by manual operation. Finished mesh from this gabion production line meets international gabion product standards.
5.After‑sales Service for Gabion Production Line
Every complete gabion production line will go through pre‑acceptance inspection before delivery. The gabion production line enjoys 12‑month warranty coverage. Suppliers provide complete operation manuals, electrical drawings and maintenance documents for the gabion production line. 24‑hour technical response and long‑term spare‑parts supply guarantee stable operation of your gabion production line.
SUPPORTING EQUIPMENT I
|
1. CNC Five-Roller Wire Tensioning Unit
Dimensions: 5800×800×600mm Rollers: 5 pcs / 20# steel Wire tension stress: 350–500N Weight: 200kg |
2. CNC Spiral Wire Forming Machine
Dimensions: 2245×928×1662mm Spiral bars: 6 bars Speed: 300r/min Spiral bar diameter: 20/25mm Servo + PLC control |
3. CNC Gabion Mesh Cutting Machine
Mesh width: 6–15cm Working width: 4000mm Motor power: 5.5kW Dimensions: 4487×2142×1565mm Weight: 2.1T |
SUPPORTING EQUIPMENT II
|
4. CNC Gabion Mesh Compact Roll Winding Machine
Roll length: 5.4m Rolling width: 0.3–5.4m Rolling speed: 30rpm Roller diameter: 102mm Dimensions: 7238×1685×2124mm Weight: 2.5T |
5. CNC Gabion Mesh Selvedging Machine
Max edge width: 4m Mesh size: 60×80 / 80×100 / 100×120mm Wire diameter: ≤3.5mm Control: PLC + HMI Function: long / short / no twist |
SUPPORTING EQUIPMENT III
|
6. CNC Hydraulic Gabion Packing Machine
Hydraulic pressure regulation: 100T Max baling size: 1.5m×3m Power supply: 380V Power: 15kW Weight: 6T |
7. CNC Wire Straightening and Cutting Machine
Wire diameter: ≤5mm Max cut length: 4m Straightening speed: 28m/min Motor power: 7.5kW Dimensions: 7134×961×1972mm |
