Gabion Production Line｜Customizable Turn‑key Gabion Mesh Weaving Production System

  1.Gabion Production Line – Turn‑key Solution Introduction

Anping Weaver supplies this one‑stop turn‑key gabion production line solution for overseas manufacturers and engineering material suppliers. Built around the SLW54C CNC gabion loom, users can select or exclude corresponding supporting machines according to actual factory layout, target product types and budget. The flexible system can be configured for pure gabion‑box production, slope‑protection roll‑mesh production, or dual‑mode mixed production to match diverse business objectives.

  2.Gabion Production Line – SLW54C Main Machine Core Capability

The SLW54C five‑axis linkage gabion weaving machine weighs 19.5 tons, with overall dimension 9.8 m ×1.32 m ×3.46 m under 380V power supply. The self‑developed control software supports UI language adjustment, production‑data statistics and interlock logic customization. Operators set mesh size, twist‑count and twist‑length on touch‑screen HMI without complicated mechanical adjustment. Maximum working width can be tailor‑made beyond standard sizes for special‑order requirements.

  3.Gabion Production Line – Optional Auxiliary Equipment Portfolio

Customers can build their own equipment portfolio: ‑ Pre‑weaving unit: CNC five‑roller wire tensioning unit, CNC wire straightening and cutting machine; ‑ In‑line processing unit: CNC spiral wire forming machine, gabion mesh cutting machine; ‑ Post‑processing unit: compact roll winding machine, selvedging machine, 100‑ton hydraulic packing machine. All auxiliary machines adopt modular design, convenient for transportation, on‑site assembly and future capacity expansion.

  4.Gabion Production Line – Global Customer Support System

Our service covers the whole cycle: pre‑sale technical proposal customization, factory pre‑acceptance, shipment packaging guidance, remote commissioning support and after‑sale maintenance. Standard warranty lasts 12 months after delivery; our engineering team offers 24‑hour online technical feedback. Complete sets of drawings, maintenance manuals and spare‑parts inventory guarantee long‑term stable running of the gabion production line at client’s workshop.
