AG1600B Fine Wire Weaving Mesh Machine with Servo Tension Control

  1. Wire Weaving Mesh Fine Wire Processing

The AG1600B combines a 1600 mm working width with a specified wire diameter range starting at 0.017 mm. Designed for fine metal fabric production, this Wire Weaving Mesh machine coordinates automatic feeding and precision weaving through an integrated electrical control system.

  2. Wire Weaving Mesh Motion Principle

Warp feeding supplies wire to the weaving zone, the rapier system performs weft insertion, and the take-up system collects the woven fabric. Servo control coordinates these movements within the Wire Weaving Mesh cycle, while the main drive operates with frequency inverter control.

  3. Wire Weaving Mesh Fabric Density Options

Fine wire cloth producers can select plain, twill or Dutch construction according to the required fabric design. The listed Wire Weaving Mesh ranges extend to 635 mesh per inch for plain and twill weaving and to 2300 mesh per inch for Dutch weave specifications.

  4. Wire Weaving Mesh Digital Adjustment

A PLC and servo integrated control platform manages the machine's operating parameters. Through the bilingual HMI, operators can review Wire Weaving Mesh machine status, adjust settings and inspect fault alarms, bringing routine production controls into a single interface.

  5. Wire Weaving Mesh Filtration Applications

Stainless steel filtration cloth and other fine metal fabrics are central application areas. The AG1600B Wire Weaving Mesh machine may support production intended for chemical filtration, battery manufacturing, hydrogen energy and aerospace applications, according to the required wire material and final fabric specification.

  6. Wire Weaving Mesh Engineering Experience

Anping Weaver Wire Mesh Equipment Manufacturing Co., LTD combines machinery manufacturing experience with a focus on intelligent equipment. Its Wire Weaving Mesh development approach emphasizes precision manufacturing, engineering discipline and configurations selected around customer production requirements.

  7. Wire Weaving Mesh Production Validation

Pre-shipment trials provide an opportunity to check machine operation against the agreed specifications. Final Wire Weaving Mesh acceptance follows installation, commissioning and stable operation at the customer's site, with product quality, safety and continuous production performance included in the acceptance basis.
