Energy Conservation Machine Gabion Box 5 Twists High Precision BWR - SLW54C
| Place of Origin | CHINA |
| Brand Name | APBWR |
| Certification | ISO9001 |
| Model Number | BWR-SLW54C |
5 twists gabion machine
,5 twists machine gabion
,high precision gabion machine
Energy Conservation Gabion Box Machine 5 Twists BWR - SLW54C
Gabion Wire Mesh Machine Product Introuction
Our team specialize in the R&D and manufacturing of high-performance gabion wire mesh machines, widely used in hydraulic engineering, slope protection, infrastructure construction, and eco-restoration projects. Featuring a self-developed 5-axis CNC linkage system, our machines lead the industry in weaving precision, operational stability, and intelligent automation. Combined with full CNC automation, modular design, and eco-friendly operation, we deliver flexible, efficient, and sustainable gabion mesh solutions for global clients.
Gabion Wire Mesh Machine Service Commitment
- 12-Month Warranty,for all machines (excluding consumables). Any non-human damages during the warranty period will receive free technical support and spare parts replacement.
- Installation & Training,provided to ensure smooth commissioning. On-site installation and training by our professional technicians are available upon request.
- Inspection & Video Confirmation,we warmly welcome customers to visit our factory for pre-shipment inspection, ensuring full confidence in the machine’s performance before delivery.If an on-site visit is not possible, we will provide high-resolution testing videos and a detailed performance report, allowing customers to verify quality prior to shipment.
We offer a range of auxiliary equipment designed to support the efficient operation of gabion mesh production lines. Customers can flexibly select and customize configurations based on their specific production needs, creating the optimal solution to enhance overall efficiency and product quality.
To meet diverse customer requirements in precision, efficiency, and weaving complexity, we offer 3-axis and 5-axis linkage drive CNC gabion mesh machines. We recommend evaluating your specific production needs before selection. Customized configuration services are also available. Please refer to the comparison chart below for more details.
3-axis systems are ideal for conventional production needs, while 5-axis drives provide higher precision, flexibility, and production efficiency—especially for demanding industrial users.
Gabion Wire Mesh Machine Comparison
5-Axis vs 3-Axis Linkage Drive in Gabion Wire Mesh Machines
| Comparison Item | 3-Axis Linkage Drive | 5-Axis Linkage Drive |
Number of Control Axes |
3 synchronized axes |
5 synchronized axes |
System Complexity |
Simpler structure and logic |
More complex and coordinated |
Twisting Precision |
Standard precision, suitable for regular mesh |
High precision for consistent and accurate twisting |
Production Efficiency |
Moderate efficiency |
Higher speed and output rate |
Supported Mesh Types |
Supports standard gabion mesh |
Capable of complex or custom mesh patterns |
Synchronization |
Good for basic operations |
Enhanced synchronization and stability |
Target Users |
For customers with standard needs |
Ideal for high-end and automated production |
Cost Investment |
Lower investment |
Higher investment due to advanced control system |
Gabion Wire Mesh Machine Performance Parameters
| Parameter | Specification | Description |
Weaving Width |
5200 mm- | Standard effective weaving width |
Wire Diameter Range |
1.5–4.5 mm (varies by spec) | Varies depending on weaving range and specification |
Mesh Size Specification |
6.6, 6.8, 7, 7.2, 8.4, 8.6, 8.8, 9, 9.2, 9.4, 10.2, 10.6, 11.6 mm | Customizable to meet various gabion requirements |
Twisting Method |
3 twists, 5 twists, long or short pitch | Available in 3-twist, 5-twist, long or short twist patterns |
Operating Speed |
Approx. 70 cycles/min | Actual speed varies based on mesh width and wire diameter |
Maximum Output |
320 m/hour | Theoretical maximum output, varies with operating conditions |
Motor Power |
15 KW × 1, 11 KW × 4 | 1 main motor and 4 auxiliary motors |
Auto Pause System |
✔ Yes / □ No | Stops automatically in case of fault or wire breakage |
Auto Lubrication System |
✔ Yes / □ No | Automatic lubrication to reduce maintenance needs |
Machine Dimensions |
9.79 × 1.40 × 3.07 m | Length × Width × Height |
Net Weight |
18.5 tons | Net weight (excluding packaging) |
CNC System |
Self-developed electronic cam system | Customizable based on customer requirements |
